The GPX family is a comprehensive family of ODU for indoor or outdoor applications , they allow to splice up to 24 fibers. they allow the connecting upstream optical cables to branching optical cable connecting the premises.
GA6A
Description
| Technical specifications | GPX51-GA3 | GPX50-GA6 | GPX50-E6D | GPX50-GA9 |
|---|---|---|---|---|
| Fibers | 24 | 4 danmark-aptk.com | 24 | 24
|
| Patch Panel | 24 Adapters SC-APC type | 4 Adapters SC-APC type | 24 Adapters SC-APC type | 24 Adapters SC-APC type |
| Splices | 24 | 4 | 24 | 4 |
| Pigtails SC-APC G657A2 | 24 max. | 4 max. | 24 max. | 4 max. |
| Installation | Wall / pole | |||
| Material | Steel, Epoxy paint | |||
| Dimensions (HxLxD) mm | 150 x 450 x 150 | 200 x 450 x 150 | 150 x 450 x 150 | 200 x 450 x 150 |
| Protections | IP40/IK08 | IP65/IK10 | ||
| Color | RAL 7035 light grey | |||
| Operating temperature | -25°c ~ +55°c (5 à 95% RH) | |||
